Dimensions (D x W x H)

537 mm x 234 mm x 493 mm

Form Factor

Mid Tower

Materials

Aluminum, Steel, Plastic

Side Panel Type

4 mm Tempered Glass Side Panel

Compatibility and Clearances

Mainboard Support

Extended ATX, ATX, Micro ATX, ITX

Maximum Motherboard Size

305 mm x 277 mm

Maximum PSU Length

280 mm

Maximum CPU Cooler Height

185 mm

Maximum GPU Length

345 mm

Access and Control

Power

1

Reset

1

USB 3.0

2

HD Audio IN

1

HD Audio OUT

1

USB Type-C

1

PCIe and Slots Drive Bays

PCIe Slots

7

3.5" HDD Bays*

2

2.5" SSD Brackets

3

Fan Capacity

Front

120mm: 3

140mm: 3

Top

120mm: 3

140mm: 3

PSU Shroud

120mm: 1

140mm: 0

Rear

120mm: 1

140mm: 1

Radiator Capacity

Front

Up to 360 mm

Top

Up to 360 mm

Rear

Up to 120 mm

Parts and Accessories

120 mm Seasonic-Nidec Fans

4

3-to-1 PWM fan splitter (pre-installed)

1

3.5" HDD Drive Bays*

2

2.5" SSD Brackets

3

Removable Dust Filters

3

Cable Management Cover

1

PSU Shroud

1

Motherboard and 2.5" SSD Screws

20

Motherboard Standoff

4

3.5" HDD Screws

18

Power Supply Screws

4

Reverse Fan Screws

4

Cable Tie

6

User Manual

1

Fabric Gloves (Pair)

1

Soft Cloth

1

80PLUS^®

Gold

Cybenetics Efficiency Level

TBA

Cybenetics Noise Level

TBA

Form Factor

Intel ATX 12 V

Dimensions

140 mm (L) x 150 mm (W) x 86 mm (H)

Fan Information

Fan Size

135 mm

Fan Control

Premium Hybrid Fan Control

Fan Bearing

Fluid Dynamic Bearing

Life Expectancy

50,000 hours at 40 °C, 15 % - 65 % RH

Cable Information

Modularity

Fully Modular

Cable type

Flat black cables

Electrical Features

Operating Temperature

0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)

MTBF @ 25 °C, excl. fan

150,000 hours

AC Input

Full Range

Protection

OPP, OVP, UVP, OCP, OTP, SCP

Safety and Environmental

Safety and EMC

cTUVus, TUV, CB, CCC, BSMI, EAC, CE

Environmental Compliance

Energy Star, RoHS, WEEE, ErP Lot 6, REACH

AC Input

Voltage:

100 V - 240 V

Current:

10 - 5 A

Frequency:

50 Hz - 60 Hz
